Sekoia.io Forwarder

The Sekoia.io Forwarder is a preconfigured collector and concentrator based on Docker. It collects events from multiple sources and forwards them to the correct intakes on the Sekoia.io platform. Each technology sends its logs to a dedicated port on the concentrator, which maps that port to the corresponding intake key.

Port isolation required

Each technology must send its logs to a distinct port on the concentrator. The forwarder uses port numbers to route events to the correct intake key.

Find the English tutorial video below. A French version is also available here.

Prerequisites

Before deploying the forwarder, verify the following:

• A x86-64 Linux host matching one of the templates below
• Last version of Docker Engine installed (see Docker Engine installation)
• Inbound TCP or UDP flows open between your log sources and the concentrator on the ports you choose
• Outbound TCP flow open toward the relevant regional host on port 10514

Host sizing recommendations

Number of assets	vCPUs	RAM (GB)	Disk size (GB)	MEMORY_MESSAGES	DISK_SPACE
1,000	2	4	200	2,000,000	180g
10,000	4	8	1,000	5,000,000	980g
50,000	6	16	5,000	12,000,000	4,980g

Sizing context

These values are based on observed averages on Sekoia.io and may vary depending on your use case. Disk type (SSD or HDD) does not affect forwarder performance, though SSD improves recovery speed when catchup is needed.

Regional hosts

Select the host address that matches your Sekoia.io region:

Region	Host address	Port
FRA1	intake.sekoia.io	10514
FRA2	intake.fra2.sekoia.io	10514
MCO1	intake.mco1.sekoia.io	10514
UAE1	intake.uae1.sekoia.io	10514
USA1	intake.usa1.sekoia.io	10514

Configure the concentrator

The concentrator requires two configuration files: docker-compose.yml and intakes.yaml.

Step 1 - Create the working directory

mkdir sekoiaio-concentrator && cd sekoiaio-concentrator

Step 2 - Create the configuration files

touch docker-compose.yml && touch intakes.yaml

Step 3 - Configure intakes.yaml

The intakes.yaml file maps each listening port to an intake key and its associated technology. For each entry, define:

Field	Description
name	A label of your choice. Not used by Sekoia.io.
protocol	tcp, udp, or tls
port	The port on which the concentrator listens for this technology
intake_key	The intake key retrieved from the Intakes page of your community

intakes.yaml with three technologies

---
intakes:
- name: Techno1
  protocol: tcp
  port: 20516
  intake_key: INTAKE_KEY_FOR_TECHNO_1
- name: Techno2
  protocol: udp
  port: 20517
  intake_key: INTAKE_KEY_FOR_TECHNO_2
- name: Techno3
  protocol: tcp
  port: 20518
  intake_key: INTAKE_KEY_FOR_TECHNO_3

Enable per-intake debug logging

To print raw received events and output messages to STDOUT for a specific intake, add debug: True to its entry. Each log line is tagged with [Input INTAKE_KEY] or [Output INTAKE_KEY].

intakes.yaml with debug enabled on Techno2

---
intakes:
- name: Techno1
  protocol: tcp
  port: 20516
  intake_key: INTAKE_KEY_FOR_TECHNO_1
- name: Techno2
  protocol: tcp
  port: 20517
  intake_key: INTAKE_KEY_FOR_TECHNO_2
  debug: True
- name: Techno3
  protocol: tcp
  port: 20518
  intake_key: INTAKE_KEY_FOR_TECHNO_3

Set a custom queue size per intake

By default, the memory queue is distributed across all intakes (MEMORY_MESSAGES divided by the number of intakes). For example, if 10 intakes are configured, each queue has a retention capacity of MEMORY_MESSAGES / 10 messages. To override this for a specific intake, add queue_size:

- name: Techno1
  protocol: tcp
  port: 20516
  intake_key: INTAKE_KEY_FOR_TECHNO_1
  queue_size: 100000

Effect on other intakes

Intakes without an explicit queue_size retain the default value calculated from MEMORY_MESSAGES.

Step 4 - Configure docker-compose.yml

docker-compose.yml template

services:
  rsyslog:
    image: ghcr.io/sekoia-io/sekoiaio-docker-concentrator:2.7.2
    environment:
      - MEMORY_MESSAGES=2000000
      - DISK_SPACE=180g
      - REGION=FRA1
    ports:
      - "20516-20566:20516-20566"
      - "20516-20566:20516-20566/udp"
    volumes:
      - ./intakes.yaml:/intakes.yaml
      - ./disk_queue:/var/spool/rsyslog
    restart: always
    pull_policy: always

Environment variables

Variable	Status	Description
MEMORY_MESSAGES	Recommended	Maximum number of messages stored in memory across all queues. Example: 2,000,000 × 1.2 KB = 2.4 GB of RAM.
DISK_SPACE	Recommended	Total disk space allocated to on-disk queues across all intakes.
REGION	Required	Target region. Accepted values: FRA1, FRA2, MCO1, UAE1, USA1.
RELP_OUTPUT	Optional	Set to True to send logs via RELP instead of the default TCP syslog mode.

Ports

The ports section exposes the concentrator's listening ports to the host network. Each entry follows the format HOST_PORT:CONTAINER_PORT. Add /udp for UDP flows.

Keep ports in sync

The port ranges declared here must match exactly the ports defined in intakes.yaml. Mismatches will silently drop traffic.

Volumes

Mount	Purpose
./intakes.yaml:/intakes.yaml	Injects your intake configuration into the container
./disk_queue:/var/spool/rsyslog	Persists on-disk queues to the host, preventing data loss if the container is recreated
./certs:/certs	Required when using TLS (see Configure TLS for an intake)
./extended_conf:/extended_conf	Mounts custom rsyslog configuration files (see Import a custom rsyslog configuration)

Restart and pull policy

Option	Value	Effect
restart	always	Automatically restarts the concentrator after a crash, a Docker restart, or a host reboot
pull_policy	always	Checks for a newer image at every docker compose up

Step 5 - Start the concentrator

Run the following command from the directory containing docker-compose.yml and intakes.yaml:

sudo docker compose up -d

To verify the concentrator is running:

sudo docker compose ps

First startup

On first run, Docker downloads the image from ghcr.io/sekoia-io/sekoiaio-docker-concentrator. This requires an outbound internet connection.

Import a custom rsyslog configuration

You can extend the concentrator with additional rsyslog configuration files to handle use cases not natively supported, such as custom input modules or advanced parsing.

To do so, create an extended_conf directory and place .conf files inside it:

mkdir extended_conf

Then mount it in docker-compose.yml:

volumes:
    - ./intakes.yaml:/intakes.yaml
    - ./extended_conf:/extended_conf
    - ./disk_queue:/var/spool/rsyslog

Do not declare the same port twice

If a port or input is defined in a .conf file inside extended_conf, do not declare it again in intakes.yaml. Duplicate bindings will prevent the concentrator from starting.

When writing custom configurations, forward events to Sekoia.io using the following template structure, replacing MY-APP-NAME and MY-INTAKE-KEY with your values:

input(type="imtcp" port="20521" ruleset="remote20521")

template(name="SEKOIAIO_Template" type="string"
    string="<%pri%>1 %timegenerated:::date-rfc3339% %hostname% MY-APP-NAME - LOG [SEKOIA@53288 intake_key=\"MY-INTAKE-KEY\"] %msg%\n")

ruleset(name="remote20521"){
    action(
        name="action"
        type="omfwd"
        protocol="tcp"
        target="intake.sekoia.io"
        port="10514"
        TCP_Framing="octet-counted"
        StreamDriver="gtls"
        StreamDriverMode="1"
        StreamDriverAuthMode="x509/name"
        StreamDriverPermittedPeers="intake.sekoia.io"
        Template="SEKOIAIO_Template"
    )
}

Route multiple technologies on a single port

Some network appliances cannot be reconfigured to send syslog to a custom port. When several technologies are hardcoded to the same destination port (for example, the standard port 514), the one-port-per-intake approach in intakes.yaml is not applicable.

The solution is to write a custom rsyslog configuration that inspects each incoming message's properties and routes it to the correct intake.

Do not declare the shared port in intakes.yaml

If port 514 is handled by a custom .conf file, it must not appear in intakes.yaml. Declaring it in both places will cause a startup failure.

Step 1 - Update docker-compose.yml

Add the shared port mapping and the extended_conf volume mount:

services:
  rsyslog:
    image: ghcr.io/sekoia-io/sekoiaio-docker-concentrator:2.7.2
    environment:
      - MEMORY_MESSAGES=2000000
      - DISK_SPACE=180g
      - REGION=FRA1
    ports:
      - "20516-20566:20516-20566"
      - "20516-20566:20516-20566/udp"
      - "514:514"
      - "514:514/udp"
    volumes:
      - ./intakes.yaml:/intakes.yaml
      - ./extended_conf:/extended_conf
      - ./disk_queue:/var/spool/rsyslog
    restart: always
    pull_policy: always

Create the extended_conf directory if it does not exist:

mkdir -p extended_conf

Step 2 - Identify a discriminating property

Before writing routing rules, inspect the raw syslog messages arriving on the shared port to identify a property that uniquely identifies each technology.

To capture live traffic on the forwarder host:

sudo tcpdump -i any -c 100 -nn -A 'port 514' | grep "LOG"

The following rsyslog properties are available for routing decisions:

Property	Description	Typical use
$fromhost-ip	Source IP as seen by the forwarder	Most reliable for network appliances
$hostname	Hostname declared in the syslog header	Identify a device by its declared name
$syslogtag	Application or program name	Identify a specific product (e.g., %ASA-)
$app-name	RFC 5424 application name field	Similar to $syslogtag for RFC 5424 senders
$msg	The log message body	Last resort when no header property is distinctive

Reading a syslog header: Windows Sysmon example

Consider the following raw syslog message:

<13>1 2026-05-07T09:49:31.308+00:00 windows-vm-0 Microsoft-Windows-Sysmon[3524] - LOG {"EventTime":"2022-09-16 12:39:18", [...] }

The syslog header fields map to rsyslog properties as follows:

Value in the message	rsyslog property	Notes
windows-vm-0	$hostname	The hostname declared by the sender in the syslog header
Microsoft-Windows-Sysmon	$app-name	The RFC 5424 application name field
3524	$procid	The process ID reported by the sender

To route all logs from this host to a Windows Sysmon intake, you could use either:

if ($hostname isequal "windows-vm-0") then { ... }

or, to match all Sysmon sources regardless of hostname:

if ($app-name isequal "Microsoft-Windows-Sysmon") then { ... }

For a complete property reference, see the rsyslog properties documentation.

Finding the right discriminant

Use tcpdump from the forwarder host to inspect raw syslog frames. Because Docker exposes the port on the host network interface, the capture works without entering the container. Typical choices: a firewall sending from a known IP uses $fromhost-ip; a VPN concentrator announcing a specific app name uses $syslogtag; a switch always sending with a hostname convention uses $hostname.

Rsyslog if conditions support the following string comparison operators:

Operator	Behavior
isequal	Exact match (case-sensitive)
contains	Substring match (case-sensitive)
contains_i	Substring match (case-insensitive)
startswith	Prefix match (case-sensitive)

Step 3 - Create the routing configuration file

Create extended_conf/port514.conf. The file must define one template per technology, one input() per protocol, one ruleset per protocol, and a fallback action for unmatched logs.

Do not load imtcp or imudp in this file

These modules are already loaded by the concentrator. Adding module(load="imtcp") or module(load="imudp") will cause a startup error.

Action names must be unique

Use suffixes such as _tcp and _udp to avoid name collisions with other rulesets.

port514.conf routing Palo Alto, Cisco ASA, and Cisco Switch

# --- Templates: one per technology ---
template(name="Tmpl_PaloAlto" type="string"
    string="<%pri%>1 %timegenerated:::date-rfc3339% %hostname% %app-name% %procid% LOG [SEKOIA@53288 intake_key=\"MY-INTAKE-KEY-PALOALTO\"] %msg%\n")

template(name="Tmpl_CiscoASA" type="string"
    string="<%pri%>1 %timegenerated:::date-rfc3339% %hostname% %app-name% %procid% LOG [SEKOIA@53288 intake_key=\"MY-INTAKE-KEY-CISCO-ASA\"] %msg%\n")

template(name="Tmpl_CiscoSwitch" type="string"
    string="<%pri%>1 %timegenerated:::date-rfc3339% %hostname% %app-name% %procid% LOG [SEKOIA@53288 intake_key=\"MY-INTAKE-KEY-CISCO-SWITCH\"] %msg%\n")

template(name="Tmpl_CatchAll" type="string"
    string="<%pri%>1 %timegenerated:::date-rfc3339% %hostname% %app-name% %procid% LOG [SEKOIA@53288 intake_key=\"MY-INTAKE-KEY-CATCHALL\"] %msg%\n")

# --- TCP listener ---
input(type="imtcp" port="514" ruleset="remote514tcp")

ruleset(name="remote514tcp") {
    if ($fromhost-ip isequal "192.168.10.5") then {
        action(
            name="fwd_paloalto_tcp"
            type="omfwd" protocol="tcp"
            target="intake.sekoia.io" port="10514"
            TCP_Framing="octet-counted"
            StreamDriver="gtls" StreamDriverMode="1"
            StreamDriverAuthMode="x509/name"
            StreamDriverPermittedPeers="intake.sekoia.io"
            Template="Tmpl_PaloAlto"
        )
        stop
    }
    if ($syslogtag startswith "%ASA-") then {
        action(
            name="fwd_ciscoasa_tcp"
            type="omfwd" protocol="tcp"
            target="intake.sekoia.io" port="10514"
            TCP_Framing="octet-counted"
            StreamDriver="gtls" StreamDriverMode="1"
            StreamDriverAuthMode="x509/name"
            StreamDriverPermittedPeers="intake.sekoia.io"
            Template="Tmpl_CiscoASA"
        )
        stop
    }
    action(
        name="fwd_catchall_tcp"
        type="omfwd" protocol="tcp"
        target="intake.sekoia.io" port="10514"
        TCP_Framing="octet-counted"
        StreamDriver="gtls" StreamDriverMode="1"
        StreamDriverAuthMode="x509/name"
        StreamDriverPermittedPeers="intake.sekoia.io"
        Template="Tmpl_CatchAll"
    )
}

# --- UDP listener ---
input(type="imudp" port="514" ruleset="remote514udp")

ruleset(name="remote514udp") {
    if ($hostname startswith "sw-") then {
        action(
            name="fwd_ciscoswitch_udp"
            type="omfwd" protocol="tcp"
            target="intake.sekoia.io" port="10514"
            TCP_Framing="octet-counted"
            StreamDriver="gtls" StreamDriverMode="1"
            StreamDriverAuthMode="x509/name"
            StreamDriverPermittedPeers="intake.sekoia.io"
            Template="Tmpl_CiscoSwitch"
        )
        stop
    }
    action(
        name="fwd_catchall_udp"
        type="omfwd" protocol="tcp"
        target="intake.sekoia.io" port="10514"
        TCP_Framing="octet-counted"
        StreamDriver="gtls" StreamDriverMode="1"
        StreamDriverAuthMode="x509/name"
        StreamDriverPermittedPeers="intake.sekoia.io"
        Template="Tmpl_CatchAll"
    )
}

Why stop is required

The stop directive prevents a matched log from being evaluated by subsequent rules. Without it, a single message could be forwarded to multiple intakes simultaneously.

TCP and UDP require separate rulesets

An rsyslog input() can only be bound to one ruleset. The routing logic is intentionally duplicated between remote514tcp and remote514udp.

Regional host

The examples above use intake.sekoia.io (FRA1). Adapt the target and StreamDriverPermittedPeers values to match your region.

Step 4 - Reload the forwarder

Apply the new configuration:

sudo docker compose up -d

Verify the container started without errors:

sudo docker compose logs | head -50

A syntax error in the .conf file will appear here and may prevent the container from starting.

Troubleshoot routing issues

Logs are not routed to the expected intake

Re-run the tcpdump capture and compare the actual syslog header values with the conditions in your .conf file. A common cause is a case mismatch. Use contains_i for case-insensitive matching while debugging.

Verify that stop is present after each matched action.

Temporarily verify routing with a file output

Add a file output action before the forwarding action to confirm a rule is matching:

module(load="omfile")

if ($fromhost-ip isequal "192.168.10.5") then {
    action(
        name="debug_paloalto_tcp"
        type="omfile"
        file="/tmp/debug-paloalto.log"
    )
    action(
        name="fwd_paloalto_tcp"
        ...
    )
    stop
}

To read the file from the host:

sudo docker compose exec rsyslog tail -f /tmp/debug-paloalto.log

Remove debug actions before going to production

File output inside the container is not persistent and will consume disk space indefinitely.

The container fails to start after adding the .conf file

Check the rsyslog error output:

sudo docker compose logs rsyslog | head -100

Common causes:

Cause	Fix
Syntax error in the .conf file	Check for missing parentheses or unknown directives
Shared port also declared in intakes.yaml	Remove it from intakes.yaml
module(load="imtcp") or module(load="imudp") present in .conf	Remove those lines
Two actions share the same name= value	Rename one of them

Configure TLS for an intake

By default, logs between your devices and the forwarder are not encrypted, even when using tcp or udp. This section shows how to enable TLS on a specific intake.

Logs between the forwarder and Sekoia.io are always encrypted with TLS regardless of this setting.

Step 1 - Generate a key and certificate

Create the certs directory and navigate to it:

mkdir certs && cd certs

Install OpenSSL if it is not already present:

Debian, UbuntuFedora, Red Hat, CentOS (yum)Fedora, Red Hat, CentOS (dnf)

sudo apt update && sudo apt install -y openssl

sudo yum update && sudo yum install -y openssl

sudo dnf update && sudo dnf install -y openssl

Generate a self-signed certificate valid for 5 years:

openssl req -x509 \
    -sha256 -days 1825 \
    -nodes \
    -newkey rsa:4096 \
    -keyout server.key -out server.crt

Set restrictive permissions on the generated files:

chmod 600 server.key server.crt

Step 2 - Mount the certs volume

Add the following line to the volumes section of docker-compose.yml:

volumes:
    - ./certs:/certs
    - ./intakes.yaml:/intakes.yaml
    - ./disk_queue:/var/spool/rsyslog

Step 3 - Update intakes.yaml

Set the protocol to tls for the relevant intake:

- name: Techno1
  protocol: tls
  port: 20516
  intake_key: INTAKE_KEY_FOR_TECHNO_1

By default, the forwarder reads the key and certificate from /certs/server.key and /certs/server.crt. To use different filenames, specify them explicitly:

- name: Techno1
  protocol: tls
  port: 20516
  intake_key: INTAKE_KEY_FOR_TECHNO_1
  tls_key_name: server
  tls_cert_name: server
  tls_ca_name: server

Monitor the concentrator

The forwarder transmits health metrics to Sekoia.io, allowing you to create detection rules for conditions such as queue saturation or service interruptions.

Step 1 - Create the forwarder logs intake

Create a dedicated intake on the Sekoia.io platform. Refer to the Sekoia.io Forwarder Logs integration documentation for detailed instructions. Save the associated intake key.

Step 2 - Enable monitoring in intakes.yaml

Add a monitoring entry with stats: True:

---
intakes:
- name: Monitoring
  stats: True
  intake_key: INTAKE_KEY_FOR_FORWARDER_LOGS

No port required

This intake is auto-generated by the forwarder. You do not need to define a port or protocol.

Understanding concentrator metrics

The concentrator uses the rsyslog impstats module to generate internal metrics. One set of metrics is produced per configured intake, identified by a dedicated name.

📸 [SCREENSHOT SUGGESTION: The forwarder monitoring metrics diagram showing per-intake metric names. | ALT TEXT: Diagram showing rsyslog metric names per intake in the Sekoia.io forwarder.]

The following detection rule pattern identifies full queues, which may lead to log loss:

detection:
  selection:
    - sekoiaio.forwarder.queue.discarded.full|gt: 0
    - sekoiaio.forwarder.queue.discarded.nf|gt: 0
    - sekoiaio.forwarder.queue.full|gt: 0
  condition: selection

For the full list of available counters, refer to the rsyslog statistic counter documentation.

Retrieve local metrics during an outage

When the forwarder cannot send metrics to Sekoia.io (for example, due to a full queue), a raw copy of the metrics is retained locally inside the container. To extract it to the host:

sudo docker compose cp rsyslog:/var/log/rsyslog-stats.log rsyslog-stats.log

Useful commands

Action	Command
Start the concentrator	sudo docker compose up -d
Check running status	sudo docker compose ps
View all logs	sudo docker compose logs
Stream logs in real time	sudo docker compose logs -f
Filter logs by intake key	sudo docker compose logs \| grep "YOUR_INTAKE_KEY"
Stop the concentrator	sudo docker compose stop
Delete the concentrator	sudo docker compose rm

Troubleshoot the concentrator

Step 1 - Verify the forwarder version

Sekoia regularly releases new versions of the forwarder. Check that you are running the latest version before investigating further.

Step 2 - Check that events are received

Enable debug mode on the relevant intake in intakes.yaml:

- name: Techno2
  protocol: tcp
  port: 20517
  intake_key: INTAKE_KEY_FOR_TECHNO_2
  debug: True

Rebuild and restart the container:

docker compose down && docker compose up -d

Stream the logs and filter by intake key:

sudo docker compose logs -f | grep "YOUR_INTAKE_KEY"

If no events appear, verify the following:

1. The intakes.yaml file declares the correct protocol and port for the expected source.
2. The declared ports are reflected in the ports section of docker-compose.yml. For example, if you configured ports 25020 to 25023, the ports line must include at least "25020-25023:25020-25023".

3. No firewall is blocking traffic from the log source:

   sudo tcpdump -c10 -nn src <remote_ip> -vv


4. The log source is configured to send to the correct IP address and port using the correct protocol.

Step 3 - Verify connectivity to Sekoia.io

1. Confirm the intake key in intakes.yaml is correct.

2. Test the outbound network flow to Sekoia.io:

   sudo apt install telnet && telnet intake.sekoia.io 10514


   A successful connection returns:

   Connected to intake.sekoia.io.
   Escape character is '^]'.


   Remove telnet after testing:

   sudo apt remove telnet


3. Check the platform status at https://status.sekoia.io.

Update the concentrator

The image version is defined in the image line of docker-compose.yml:

image: ghcr.io/sekoia-io/sekoiaio-docker-concentrator:2.7.2

To update, change the version tag and recreate the container:

sudo docker compose up -d

All available versions are listed on the GitHub container registry.

Using the latest tag

The latest tag always resolves to the most recent version. With pull_policy: always, the image is updated on every docker compose up.

Use latest with caution in production

A major version change could break your current configuration. Pin to a specific version in production environments.

Weekly security patches

Each image version is rebuilt weekly with the latest OS security patches. You are responsible for recreating the container periodically to apply them.

Add a new intake

1. Edit intakes.yaml and add the new entry:

   - name: NewIntake
     protocol: tcp
     port: 20519
     intake_key: INTAKE_KEY_FOR_NEW_INTAKE


2. Verify that the new port falls within the range already declared in docker-compose.yml. If not, expand the range:

   ports:
     - "20516-20566:20516-20566"
     - "20516-20566:20516-20566/udp"


3. Recreate the concentrator:

   sudo docker compose up -d


4. Confirm the new intake appears in the startup logs:

   sudo docker compose logs | more


Docker Engine installation

This section covers Docker Engine installation on Debian 64-bit (Bullseye 11 or Buster 10). For other Linux distributions, refer to the official Docker documentation.

Uninstall previous versions

sudo apt-get remove docker docker-engine docker.io containerd runc

Set up the apt repository

1. Update the package index and install HTTPS transport dependencies:

   sudo apt-get update
   sudo apt-get install ca-certificates curl gnupg lsb-release


2. Add Docker's official GPG key:

   sudo mkdir -m 0755 -p /etc/apt/keyrings
   curl -fsSL https://download.docker.com/linux/debian/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg


3. Add the Docker repository:

   echo \
     "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/debian \
     $(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null


Install Docker Engine

1. Update the package index:

   sudo apt-get update


2. Install Docker Engine and its components:

   sudo apt-get install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin


3. Verify the installation:

   sudo docker run hello-world


5-minute setup on Debian

This script automates all the steps on this page for a Debian host.

Read before running

Review the full content of this page before executing the script. The script applies all default settings without prompting for confirmation.

Step 1 - Download and run the setup script:

wget https://raw.githubusercontent.com/SEKOIA-IO/documentation/main/docs/assets/operation_center/ingestion_methods/sekoiaio_forwarder/sekoiaio_docker_concentrator_autosetup.sh
chmod +x sekoiaio_docker_concentrator_autosetup.sh
./sekoiaio_docker_concentrator_autosetup.sh
rm sekoiaio_docker_concentrator_autosetup.sh

Step 2 - Edit the generated configuration files:

• In sekoiaio-concentrator/intakes.yaml, replace the name, protocol, port, and intake_key values for each intake.
• In sekoiaio-concentrator/docker-compose.yml, update the port range to match your intakes.yaml.

Step 3 - Start the concentrator:

sudo docker compose up -d
sudo docker compose ps
sudo docker compose logs -f

Additional resources

The forwarder image is maintained on the sekoiaio-docker-concentrator GitHub repository. Contributions and pull requests are welcome.
